封装类型
SMB/DO-214AA
Pppm@ 10/1000μs (W)
600
VRWM Max. (V)
8.6
VBR@IT Min. (V)
9.5
VBR@IT Max. (V)
10.5
IT (mA)
1
VC@IPP Max. (V)
14.5
IPP@Max 10/1000μs (A)
41.38
IR@VRWM Max. (uA)
10
AEC-Q101
NO
P6SMB Series.pdf
