规格型号
| Product Image |
封装类型
|
类型
|
VDS
(V) |
VGS
(V) |
VTH
(MIN) (V) |
VTH
(MAX) (V) |
ID
@25°C (A) |
RDS(ON)
@VGS=10V Typ(mΩ) |
RDS(ON)
@VGS=10V Max(mΩ) |
RDS(ON)
@VGS=4.5V Typ.(mΩ) |
RDS(ON)
@VGS=4.5V Max(mΩ) |
RDS(ON)
@VGS=2.5V Typ.(mΩ) |
RDS(ON)
@VGS=20V Typ (mΩ) |
ESD
|
AEC-Q101
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | SOT-23 | NMOS | 60 | ±20 | 1 | 2.5 | 0.34 | 900 | 2500 | 1100 | 3000 | / | - | NO | NO | |
 | SOT-26 | NMOS | 100 | ±20 | 0.8 | 2.0 | 0.3 | 3200 | 6000 | 3800 | 10000 | / | - | YES | NO | |
 | DFN1006-3L | NMOS | 100 | ±20 | 0.8 | 2.0 | 0.28 | 3200 | 6000 | 3800 | 10000 | / | - | YES | NO | |
 | SOT-26 | NMOS | 20 | ±12 | 0.6 | 1.5 | 6.0 | / | / | 20 | 25 | 24 | - | NO | NO | |
 | SOT-26 | NMOS | 20 | ±12 | 0.5 | 1.2 | 6.8 | / | / | 13 | 14.5 | 17 | - | NO | NO | |
 | SOT-363 | NMOS | 20 | ±12 | 0.35 | 1.1 | 0.63 | / | / | 270 | 380 | 320 | - | YES | NO | |
 | SOT-363 | PMOS | -20 | ±12 | -0.35 | -1.1 | -0.66 | / | / | 350 | 510 | 480 | - | YES | NO | |
 | SOT-23 | NMOS | 20 | ±12 | 0.5 | 1.0 | 6 | / | / | 16 | 21 | 20 | - | NO | NO | |
 | SOT-23 | NMOS | 20 | ±12 | 0.4 | 1.0 | 5 | / | / | 17 | 19 | 24 | - | YES | NO | |
 | SOT-26 | NMOS | 20 | ±12 | 0.5 | 1.3 | 7 | / | / | 11.8 | 14.5 | 17 | - | YES | NO | |
 | SOT-26 | NMOS | 20 | ±10 | 0.35 | 1.0 | 0.88 | / | / | 190 | 350 | 250 | - | YES | NO | |
 | SOT-523 | NMOS | 20 | ±12 | 0.35 | 1.1 | 0.5 | / | / | 190 | 380 | 260 | - | YES | NO | |
 | SOT-723 | NMOS | 20 | ±12 | 0.35 | 1.1 | 0.75 | / | / | 170 | 330 | 230 | - | YES | NO | |
 | DFN1006-3L | NMOS | 20 | ±12 | 0.35 | 1.1 | 1.0 | / | / | 190 | 300 | 250 | - | YES | NO | |
 | SOT-26 | PMOS | -20 | ±12 | -0.5 | -1.0 | -2.0 | / | / | 85 | 120 | 110 | - | NO | NO |
